M2705-66510 /M2703-66450 Philip FM20 FM30 FETAL MONITOR MAINBOARD
Ürün ayrıntıları:
| Menşe yeri: | Orijinal |
| Marka adı: | philip |
| Model numarası: | FM20 FM30 |
Ödeme & teslimat koşulları:
| Min sipariş miktarı: | 1 |
|---|---|
| Fiyat: | Negotiation, pls contact me |
| Ambalaj bilgileri: | Karton kutu |
| Teslim süresi: | Ödeme onaylandıktan sonra 1-2 iş günü içinde |
| Ödeme koşulları: | Banka havalesi, Western Union |
| Yetenek temini: | 10 |
|
Detay Bilgi |
|||
| PN: | M2705-66510 /M2703-66450 | Modeli: | FM20 FM30 |
|---|---|---|---|
| cihazlar: | Tıbbi ekipman | Durum: | İyi |
| Garanti: | 3 Ay | ||
| Vurgulamak: | Philip FM20 fetal monitor mainboard,Philip FM30 fetal monitor replacement part,fetal monitor mainboard with warranty |
||
Ürün Açıklaması
M2705-66510 /M2703-66450 Philip FM20 FM30 FETAL MONITOR MAINBOARD
1. Main CPU Board (Mainboard Core)
- Part Number: M2703-66450 (also referenced as M2705-66510)
- CPU Core: 32-bit embedded RISC processor (medical-grade, real-time OS)
- Clock Speed: 200 MHz (typical)
- Memory:
- Flash: 128 MB (firmware, calibration, user presets)
- RAM: 64 MB (real-time data, waveforms, trend buffers)
- Data Storage: 72-hour fetal/maternal trend data; 800 NIBP records
- Embedded OS: Philip proprietary real-time OS (RTOS) for medical devices
- Digital Signal Processing (DSP):
- FHR (ultrasound) signal processing: 50–240 bpm, ±2 bpm accuracy
- TOCO (uterine contraction) signal conditioning: 0–100 TOCO units
- Smart Pulse™: cross-channel coincidence detection (FHR vs maternal pulse)
2. Bus Master Board (System Control & I/O Hub)
- Part Number: M2703-66460
- System Bus: CAN bus (medical device standard) + parallel/digital I/O
- Power Management:
- Input: 100–240 VAC, 50/60 Hz; 24 VDC (battery backup)
- Output: 5 VDC (logic), ±12 VDC (analog), 24 VDC (printer/transducers)
- Overvoltage/overcurrent/ESD protection (IEC 60601-1 compliant)
- Interface Ports (Onboard + Expansion):
- Fetal: 2× ultrasound (US) ports, 1× TOCO port, fetal movement input
- Maternal (optional): 3-lead MECG, SpO₂, NIBP
- Printer: Thermal printhead interface (150 mm, 8 dots/mm)
- Display: 6.5” TFT LCD (800×480) + touchscreen controller (optional)
- Data/Control: USB 2.0, LAN (Ethernet), RS-232, PS/2, nurse call relay
3. Combined Mainboard (CPU + Bus Master) Key Specs
- Architecture: Dual-board (CPU + Bus Master) stack, 4-layer PCB, medical-grade components
- PCB Dimensions: ~220 × 180 mm (per board)
- Operating Temp: +5°C to +45°C
- Storage Temp: -20°C to +60°C
- Humidity: 10–95% RH (non-condensing)
- Compliance: IEC 60601-1, IEC 60601-2-37, EN 60601-1
- Lifetime: ≥5 years (clinical use); designed for 24/7 continuous operation
4. Critical Onboard Subcircuits
- Ultrasound Frontend: 1 MHz pulsed wave, 9-element transducer support, IPX8
- TOCO Frontend: Bridge amplifier, 0–5 V analog output, noise filtering
- MECG (Optional): 3-lead, 0.05–100 Hz bandwidth, 50/60 Hz notch filter
- SpO₂ (Optional): Philip FAST SpO₂, anti-motion/low-perfusion algorithm
- NIBP (Optional): Oscillometric method, 60–240 mmHg systolic, 30–180 mmHg diastolic
